Waterproof Gland Cable Entry

Nylon Cable Glands are quick & easy to install with a high quality gripping claw/seal arrangement that caters for a wide range of cable sizes per fitting. Each gland has no loose parts and requires no disassembly for cable installation.

• Applications: Indoor and outdoor use

• Standards: AS1939 - 1990

• Function: Provides seal on cable sheath

• Protection Class: IP68, Resistant to salt water, weak alcohol, oil, grease and common solvents

• Construction Body: UL approved Nylon 66 (Black or White)

• Seal: EPDM Rubber Thread Type Metric with locknut and IP68 washer

Mounting Thread Size/Length: M20 x 1.5mm

Cable Diameter: 8.5-14mm

Colours: Black or White

Cable Entry Qty: Single or Dual

Dimensions: Up to L121.00mm x W38.90 x H43.80mm
